Analytical design methodology for wind power permanent magnet synchronous generators

Ballestín-Bernad, V. (Universidad de Zaragoza) ; Artal-Sevil, J.S. (Universidad de Zaragoza) ; Domínguez-Navarro, J.A. (Universidad de Zaragoza)

Resumen: In this paper a novel analytical design methodology for wind power permanent magnet synchronous generators is presented. This kind of electric generator plays a major role in small-scale wind energy conversion systems up to 10 kW. The proposed diameter-cubed sizing equation is based both on the generator requirements, imposed by the application, and the design parameters that rely on the designer criteria. The magnetic field waveforms of both the permanent magnets field and the armature field are considered from the first moment through the winding factors, as well as the slots effects given by the Carter factor. The analytical model of the permanent magnet synchronous generator is validated with the finite element method, showing good agreement, both with no load and under load. As the generator is unsaturated, the main source of divergence between the analytical and the finite element model are the iron losses, due to the nonuniform magnetic field distribution.

Idioma: Inglés

DOI: 10.24084/repqj21.418

Año: 2023

Publicado en: Renewable Energy and Power Quality Journal 21, 1 (2023), 606-612
ISSN: 2172-038X

Factor impacto CITESCORE: 0.7 - Electrical and Electronic Engineering (Q4) - Renewable Energy, Sustainability and the Environment (Q4) - Energy Engineering and Power Technology (Q4)

Factor impacto SCIMAGO: 0.152 - Electrical and Electronic Engineering (Q4) - Renewable Energy, Sustainability and the Environment (Q4) - Energy Engineering and Power Technology (Q4)

Financiación: info:eu-repo/grantAgreement/EUR/AEI/TED2021-129801B-I00
Financiación: info:eu-repo/grantAgreement/ES/MCIU/FPU20/03436

Tipo y forma: Artículo (Versión definitiva)

Área (Departamento): Área Ingeniería Eléctrica (Dpto. Ingeniería Eléctrica)
